GNSS Receiver - EM-506N5

The USGlobalSat EM-506N5 GPS receiver is based on the high-performance L1 band GNSS receiver from MediaTek. It's an upgraded version of the EM-506. This amazing receiver comes with on-board voltage regulation, an LED status indicator, battery-backed RAM, and a built - in patch antenna. Note that the 6 - pin interface cable is not included. Powered by the MediaTek L1 band GNSS receiver, it offers superior sensitivity and performance, even in tough urban canyon and dense foliage environments. Not sure which GPS module suits you? Check out our GPS Buying Guide! Key features include high - level sensitivity (tracking at - 165dBm and cold start acquisition at - 148dBm), fast start - up times (less than 1 second for hot start, 15 seconds for warm start, and 35 seconds for cold start), and excellent accuracy in horizontal position (less than 2.5m) and velocity. It also has a wide range of operation and storage temperatures, making it suitable for various conditions. The product also comes with a datasheet for your reference.

Using the USGlobalSat EM - 506N5 GPS receiver is quite straightforward. First, connect the power supply. Make sure the voltage is within the range of 4.5V to 6.5V. Once powered on, the LED status indicator will show the working status. Wait for the receiver to acquire satellite signals. In general, it can achieve a hot start in less than 1 second, a warm start in less than 15 seconds, and a cold start in less than 35 seconds. You can use it to get accurate position and velocity information. When using it, avoid placing it in areas with strong interference. Also, keep in mind that the 6 - pin interface cable is not included, so you need to prepare it separately. For maintenance, keep the receiver in a dry environment with humidity between 5% and 95% (non - condensing). The operation temperature should be between - 40°C and 85°C. If you don't use it for a long time, store it in a cool and dry place with a temperature range of - 40°C to 85°C. Check the datasheet regularly for more detailed information about the product's performance and usage.
